Leon Sling
Available on
Features
Outstanding Outdoor Performance
If outdoors is where you want to be, the Leon will take you there. The full four-wheel suspension offers extra comfort and a smooth ride. With driving speed up to 8mph (12.5 km/hr), the strong motors overcome most rough terrain. The optional 70 Ah batteries extend the driving range for longer trips.
Excellent Indoor Manoeuvrability
The Leon’s total width is 62 cm, making it one of the most compact power wheelchair on the market. Smooth and easy to navigate, this chair moves effortlessly through doorways, onto lifts, and around confined spaces.
Compatible with 2 Power Positioning Modular
The Sling Seat has an optional power tilt seating system that uses the tilt-in-space function to tilt the chair from 0° to 23°. Tilting the body back will shift weight to the user’s back thus shifting pressure away from the hipbone and redistributing it over a larger surface area. This feature helps reduce the risks of developing pressure ulcer and avoid back pain.Modular Power Recline
The Sling Seat has an optional power recline seating system that offers the ability to recline the backrest from 0° to 32°. This allows the users to stretch their hip joint and relax the back muscle. The two power functions can be implemented individually or in conjunction with each other on a sling seat.
Adjustable Seat Depth and Angle
The Leon Sling seat offers various adjustability. The seat depth can be adjusted from 41 cm to 46 cm. The backrest can be angled from -1° to 11°.Contour Adjustable Headrest
The height and angle of the headrest are both adjustable. The headrest curved ergonomically according to the shape of the neck.
| Nominal seat width | 18” | 20” |
|---|---|---|
| Max Speed | 8mph / 12.5km | |
| Range | 18 miles / 26km | |
| Maximum user weight | 21st / 136kg | |
| Dimensions LxWxH | 1060*620*1230 (with the headrest) | |
| Seat width | 460 mm | 510 mm |
| Seat depth | 430 mm | 480 mm |
| Front seat height | 530 mm | 510 mm |
| Backrest height | 530 mm | 480 mm |
| Seat angle | 12X° | 9X° |
| Back angle | 0 – 65X° | 0 – 45X° |
| Armrest height | 210 – 310 mm | |
| Legrest length | 390 – 520mm | |
| Power Functions | Manual Tilt：0°~65° | Manual Tilt：0°~45° |
| Suspension | 4 shock absorber | |
| Motor (nominal output) | DC 450W/4P | |
| Batteries | 50Ah x2 Optional 60 & 70Ah | |
| Controller | VR2 | |
| Wheels | Caster 230mm(9”) )/ Pneumatic Tire Rear Wheel 355mm(14”) )/ Pneumatic Tire | |
| Max Safe Slope | 8° | |
| Maximum obstacle climbing ability | 50 mm | |
| Min. Turning Radius | 780 mm | |
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
*** Drive range/ Ability to climb rated slope are estimated based on the following conditions: 20℃~35℃, 136 kg occupant, brand new fully charged batteries and driving on the flat road. – The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg. – The actual product specifications may vary according to different configurations. – KARMA reserves the right to modify information herein without further notice.
